EPSON Impact Mini Printers Shuttle impact dot matrix M-160.pdf printer

Product name：EPSON Impact Mini Printers Shuttle impact dot matrix M-160.pdf printer

Item：EPSON Impact Mini Printers Shuttle impact dot matr

Details：

EPSON Impact Mini Printers Shuttle impact dot matrix M-160.pdf printer

Epson M-160 Series

Impact Mini Printers

Ultra-compact and very reliable

Printing Format
Printing Method	Shuttle impact dot matrix
Font	5 x 7
Column capacity	M-150II: 16 columns M-160: 24 columns M-163: 32 columns M-164: 40 columns
Character size	M-150II: 1.8 (W) x 2.5 (H)mm M-160: 1.7 (W) x 2.4 (H)mm M-163: 1.3 (W) x 2.4 (H)mm M-164: 1.1 (W) x 2.4 (H)mm
Line spacing	M-150II: 3.5mm (For a 5 x 7 font and 3 dots per line paper feed) M-160:/M-163/M-164: 3.3mm (For a 5 x 7 font and 3 dots per line paper feed)
Column spacing	M-150II: 2.1mm M-160: 2.0mm M-163: 1.5mm M-164: 1.2mm
Number of total dots	M-150II: 96 dots / line M-160: 144 dots / line M-163: 192 dots / line M-164: 240 dots / line
Printing Speed	M-150II: 1.0 line / sec. M-160: 0.7 line / sec. M-163: 0.5 line / sec. M-164: 0.4 line / sec.
Printhead
Terminal Voltage	3.0 to 5.0 VDC
Peak current	Approx. 3 A / solenoid
Motor
Terminal Voltage	3.8 to 5.0 VDC
Mean current	M-150II: Approx. 0.17 A M-160/M-163/M-164: Approx. 0.2 A
Paper
Dimensions	M-150II: 44.5 ± 0.5mm (W) x dia. 50mm max. M-160/M-163/M-164: 57.5 ± 0.5mm (W) x dia. 50mm max.
Total Thickness	0.07mm
Copy Capability	Original + one copy
Ribbon Cassette	M-150II: ERC-05 M-160/M-163/M-164: ERC-09/22
Ambient Temperature	0° to 50°C (operating)
Reliability
Mechanism (MCBF)	M-150II: 0.5 x 10⁶ lines M-160/M-163/M-164: 0.4 x 10⁶ lines
Printhead Life	M-150II: 0.5 x 10⁶ lines M-160/M-163/M-164: 0.4 x 10⁶ lines
Overall Dimensions	M-150II: 73.2 (W) x 42.6 (D) x 12.8 (H)mm M-160/M-163/M-164: 91.0 (W) x 42.6 (D) x 12.8 (H)mm
Weight	M-150II: Approx. 60 g M-160/M-163/M-164: Approx. 75 g

Printing Format
Printing Method	Shuttle impact dot matrix
Font	5 x 7
Column capacity	M-150II: 16 columns M-160: 24 columns M-163: 32 columns M-164: 40 columns
Character size	M-150II: 1.8 (W) x 2.5 (H)mm M-160: 1.7 (W) x 2.4 (H)mm M-163: 1.3 (W) x 2.4 (H)mm M-164: 1.1 (W) x 2.4 (H)mm
Line spacing	M-150II: 3.5mm (For a 5 x 7 font and 3 dots per line paper feed) M-160:/M-163/M-164: 3.3mm (For a 5 x 7 font and 3 dots per line paper feed)
Column spacing	M-150II: 2.1mm M-160: 2.0mm M-163: 1.5mm M-164: 1.2mm
Number of total dots	M-150II: 96 dots / line M-160: 144 dots / line M-163: 192 dots / line M-164: 240 dots / line
Printing Speed	M-150II: 1.0 line / sec. M-160: 0.7 line / sec. M-163: 0.5 line / sec. M-164: 0.4 line / sec.
Printhead
Terminal Voltage	3.0 to 5.0 VDC
Peak current	Approx. 3 A / solenoid
Motor
Terminal Voltage	3.8 to 5.0 VDC
Mean current	M-150II: Approx. 0.17 A M-160/M-163/M-164: Approx. 0.2 A
Paper
Dimensions	M-150II: 44.5 ± 0.5mm (W) x dia. 50mm max. M-160/M-163/M-164: 57.5 ± 0.5mm (W) x dia. 50mm max.
Total Thickness	0.07mm
Copy Capability	Original + one copy
Ribbon Cassette	M-150II: ERC-05 M-160/M-163/M-164: ERC-09/22
Ambient Temperature	0° to 50°C (operating)
Reliability
Mechanism (MCBF)	M-150II: 0.5 x 10⁶ lines M-160/M-163/M-164: 0.4 x 10⁶ lines
Printhead Life	M-150II: 0.5 x 10⁶ lines M-160/M-163/M-164: 0.4 x 10⁶ lines
Overall Dimensions	M-150II: 73.2 (W) x 42.6 (D) x 12.8 (H)mm M-160/M-163/M-164: 91.0 (W) x 42.6 (D) x 12.8 (H)mm
Weight	M-150II: Approx. 60 g M-160/M-163/M-164: Approx. 75 g

Printing Format
Printing Method	Shuttle impact dot matrix
Font	5 x 7
Column capacity	M-150II: 16 columns M-160: 24 columns M-163: 32 columns M-164: 40 columns
Character size	M-150II: 1.8 (W) x 2.5 (H)mm M-160: 1.7 (W) x 2.4 (H)mm M-163: 1.3 (W) x 2.4 (H)mm M-164: 1.1 (W) x 2.4 (H)mm
Line spacing	M-150II: 3.5mm (For a 5 x 7 font and 3 dots per line paper feed) M-160:/M-163/M-164: 3.3mm (For a 5 x 7 font and 3 dots per line paper feed)
Column spacing	M-150II: 2.1mm M-160: 2.0mm M-163: 1.5mm M-164: 1.2mm
Number of total dots	M-150II: 96 dots / line M-160: 144 dots / line M-163: 192 dots / line M-164: 240 dots / line
Printing Speed	M-150II: 1.0 line / sec. M-160: 0.7 line / sec. M-163: 0.5 line / sec. M-164: 0.4 line / sec.
Printhead
Terminal Voltage	3.0 to 5.0 VDC
Peak current	Approx. 3 A / solenoid
Motor
Terminal Voltage	3.8 to 5.0 VDC
Mean current	M-150II: Approx. 0.17 A M-160/M-163/M-164: Approx. 0.2 A
Paper
Dimensions	M-150II: 44.5 ± 0.5mm (W) x dia. 50mm max. M-160/M-163/M-164: 57.5 ± 0.5mm (W) x dia. 50mm max.
Total Thickness	0.07mm
Copy Capability	Original + one copy
Ribbon Cassette	M-150II: ERC-05 M-160/M-163/M-164: ERC-09/22
Ambient Temperature	0° to 50°C (operating)
Reliability
Mechanism (MCBF)	M-150II: 0.5 x 10⁶ lines M-160/M-163/M-164: 0.4 x 10⁶ lines
Printhead Life	M-150II: 0.5 x 10⁶ lines M-160/M-163/M-164: 0.4 x 10⁶ lines
Overall Dimensions	M-150II: 73.2 (W) x 42.6 (D) x 12.8 (H)mm M-160/M-163/M-164: 91.0 (W) x 42.6 (D) x 12.8 (H)mm
Weight	M-150II: Approx. 60 g M-160/M-163/M-164: Approx. 75 g

Usage Conditions
Epson products are designed and made to give highly reliable use and long life when used according to its specifications. With any system, product or device used in situations where human life may be involved or at risk, Epson advises that you should take all necessary steps to ensure the suitability of your Epson product for inclusion in your system, and recommends that you include fail-safe procedures and redundancy support or backup equipment in your system, to maintain the maximum safety margin and optimum system reliability.
