LTP3000 Series

LTP3245

LTP3345

LTP3445

The LTP3000 Series thermal line printers combine a compact, lightweight battery-powered design with an array of advanced features. This series is the ideal thermal printing solution for any application where small size, speed, versatility and low-power consumption are critical. Aside from being efficient, economical and dependable, the LTP3000 Series printers feature 5 volt operation and a power-saving design that supports virtually any application requiring portable, battery-powered thermal printing.

Features

• High speed (56.25mm/sec. attainable with LTP3445)
• High resolution printing (8 dots/mm)
• Low voltage operation
• Accepts two-ply and label media
• Head-up and paper-out sensors
• High reliability
• Quiet operation

Model		LTP3245 A/B	LTP3245 F/G	LTP3345	LTP3445
Print system		Thermal line dot system
Head up / down detection		Detection by mechanical switch
Paper detection		Detection by photo interrupter
Dot resolution (dots / mm)		8
Dot configuration (dots / line)		384	384	384	384
Printing speed (mm /sec.) (Max.)		22.5 (180 dotlines / sec.	54.5 (437 dotlines / sec.)	45 (360 dotlines / sec.) during 7V drive	56.25 (450 dotlines / sec. During 8.5V drive 50 (400 dotlines / sec.) during 7.2V drive
Printing width / Paper width (mm)		48 / 58		72 / 80	104 / 112
Thermal head service life	Anti-pulse characteristic	5 x 107pulses
	Abration resistance	30 km			50 km
Operating voltage range (V)	Logic	4.2 to 5.5		4.5 to 5.5
	Head	4.2 to 6.0	4.2 to 7.0	4.2 to 7.0	4.2 to 8.5
Dimensions (W x D x H) (mm)		76.3 x 50 x 20	76 x 54 x 21	97 x 57 x 21	129 x 51 x 21
Weight (g)		Approx. 80	Approx. 105	Approx. 115	Approx. 135
Technical Reference		(Size:472KB)	(Size:618KB)	(Size:694KB)	(Size:624KB)
