打印方式
打印速度
纸宽
接口类型
切纸方式
可靠性打印
打印字符
电源
驱动
打印命令
外型尺寸
一维条码
二维条码

行式热敏
50mm/s(Max)
57.5±0.5mm
以太网/USB/并口/串口
手撕
50公里
ASCII/GB2312简体中文/繁体中文/多国字符集
DC12V/2A
Win2000/WinXP/Win Vista/Win7/Linux
兼容ESC/POS命令
135×215×113mm(宽×深×高）
Code 39 ，Code 128subsets A.B.C. ， Code 11，Codebar，interleaved 2 of 5，EAN-13, UPC-A,PUC-E
QR Code， PDF-417

Print

Printing Method

Thermal Line

Printing Speed

50mm/s

Resolution

8dots/mm,  384dots/line

Effective Printing Width

48 mm

Character

ANK Character Set

12 x24 dot 1.25(width) x3.00(height)mm

International Standard Ⅰ、Ⅱ

Class Chinese Set

12 x24 dot 3.00(width) x3.00(height)mm

Character per Line

32CPL

Paper Spec

Paper Type

Thermal paper

Paper Width

57.5± 0.5mm

Paper Roll Diameter

Max:  58.0mm

Roll Core Inner Diamete

10mm(min.)

Paper Thickness

 53～60g/㎡

Paper Supply Method

Easy Load

Paper Solve Method

Manual

Reliability

MCBF

15 million lines

TPH

50km

Emulation

ESC/POS

Driver

Win2000/2003/XP/Vista/Win7

Sensor

Paper End Sensor

Drawer Port

1 Port

Interface

RS-232, Parallel, USB

Power Supply (Adapter)

AC100 ~240V ± 10%(include) DC 12V, 2A

Physical

Net Weight

1kg(without paper roll)

Gross Weight

1.5kg

Printer Dimension

198（L）×120（W）×112（H）mm

Color

white/black
