LTPC245A-C384-E |
|
| 产品名称：LTPC245A-C384-E |
| 产品编号：LTPC245A-C384-E |
| 详细说明： |
CAPC Series Specifications
| Model |
CAPC235 |
CAPC245 |
| Printing |
Method |
Thermal line dot printing |
| Number of dots/line |
288 |
| Resolution (dots/mm) |
6 |
| Paper width (mm) |
58 |
| Printing width (mm) |
48 |
| Max speed (mm/sec) |
60 |
| Paper path |
Curved |
| Head temperature |
By thermistor |
| Platen position detection |
By mechanical switch |
| Detection |
Out of paper detection |
By photo interrupter |
| Cutter home position |
By mechanical switch |
| Power supply (V) |
Operating voltage (Vdd) |
4.75 to 5.25 |
| Operating voltage (Vp) |
5.8 to 8.0 |
| Peak current (A) |
Head |
4.6 (8V/144 dots) |
4.3 (8V/96 dots) |
| Motor |
.82 (8V) |
| Cutter |
2.2 |
| Cutting |
Method |
Slide type |
| Paper thickness |
54 to 80 |
| Cutting type |
Partial cut (Right side edge remains) |
| Operating time(max sec/cycle) |
1 |
| Min cutting pitch (mm) |
10 |
| Cut frequency(max cuts/min) |
30 |
| Service life |
Pulse activation |
50 million |
100 million |
| Abrasion resistance (km) |
50* |
| Life (cuts) |
500,000 |
| Operating temperature (°C) |
-20 to 50 |
| Dimensions (WxDxH mm) |
71.1 x 88.6 x 29.0** |
| Mass (g) |
Approx. 220 |
LTPC Series Specifications
| Model |
|
LTPC235 |
LTPC245 |
| Printing |
Method |
Thermal line dot printing |
| Number of dots/line |
288 |
| Resolution (dots/mm) |
6 |
| Paper width (mm) |
58 |
| Printing width (mm) |
48 |
| Max speed (mm/sec) |
60 |
| Paper path |
Curved |
| Head temperature |
By thermistor |
| Platen position detection |
By mechanical switch |
| Detection |
Out of paper detection |
By photo interrupter |
| Cutter home position |
By mechanical switch |
| Power supply (V) |
Operating voltage (Vdd) |
4.75 to 5.25 |
| Operating voltage (Vp) |
5.8 to 8.0 |
| Peak current (A) |
Head |
4.6 (8V/144 dots) |
4.3 (8V/96 dots) |
| Motor |
.82 (8V) |
| Cutter |
-- |
-- |
| Cutting |
Method |
-- |
-- |
| Paper thickness |
-- |
-- |
| Cutting type |
-- |
-- |
| Operating time (max sec/cycle) |
-- |
-- |
| Min cutting pitch (mm) |
-- |
-- |
| Cut frequency (max cuts/min) |
-- |
-- |
| Service life |
Pulse activation |
50 million |
100 million |
| Abrasion resistance (km) |
50* |
| Life (cuts) |
-- |
-- |
| Operating temperature (°C) |
-20 to 50 |
| Dimensions (WxDxH mm) |
71.1 x 88.6 x 29.0** |
| Mass (g) |
Approx. 220 |
CPU
| Model |
PT800P01 |
| Thermal printer |
CAPC235/LTPC235 |
CAPC245/LTPC245 |
| Package form |
80 pin QFP |
| Operating voltage (V) |
Vp: 5.0 to 8.0, Vcc: 4.5 to 5.5 |
| Operating frequency (MHz) |
5 + .5% |
| Configuration |
C-MOS LSI |
| Interface |
Parallel, Serial |
| Character type |
Extended graphics character set, Other characters are available with CGs *1 or external ROM |
| Character matrix (H x W dots) |
16 dot characters : 16 x 8, 16 x 16
24 dots characters : 24 x 12, 24 x 24 |
| Dimensions (W x D x H mm) |
17.2 x 17.2 x 1.7 |
(with cutter)
LTPC Series and CAPC Series with auto-cutter are innovative 2" direct thermal printer mechanisms designed for portable printing applications. Both series are available with the PT800P01 processor, supporting Parallel and Serial interface connectivity.
- Low operating voltage for longer battery life
- Choice of 6 dots/mm or 8 dots/mm resolution
- EZ-OP clamshell paper replacement
|
 |
