Thermal Printer Mechanisms—M-T500 Series
Super-fast, high-performance printers |
 |
| Product: |
|
M-T512A, 522A, 532A and 542A—straight paper path |
|
|
| Features: |
· |
Prints up to 150 mm (5.9 inches) per second |
| |
· |
Deliver fast throughput even in Full-Graphic Mode (uses BA-T500) |
| |
· |
Easily handle thick paper and tickets up to 180 um (7.1 mils) |
| |
· |
Handles large diameter paper rolls of up to 254 mm (10 inches) with additional feed assist mechanism |
| |
· |
Designed with easy and convenient semi-auto paper loading, and a full paper path opening mechanism for easy paper jam removal and head cleaning |
| |
· |
Full or partial cut autocutter is standard |
| |
· |
Available with high speed cutter |
| |
· |
RS-232 serial and IEEE 1284 bi-directional interfaces for direct PC connection |
| |
· |
Handles large diameter paper rolls of up to 254mm (10 inches) with additional feed assist mechanism |
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
 |
|
|
Specifications |
|
M-T512A |
|
M-T522A |
|
M-T532A |
|
M-T542A |
|
|
|
|
Paper Width |
|
57.5 ± 0.5 mm |
|
59.5 ± 0.5 mm |
|
79.5 ± 0.5 mm |
|
82.5 ± 0.5 mm |
|
|
|
|
Paper Path |
|
straight |
|
|
|
|
Number of Total Dots |
|
448 dots/line |
|
640 dots/line |
|
|
|
|
Resolution |
|
8 dots/mm |
|
|
|
|
Printing Speed |
|
max. 150 mm/sec. |
|
|
|
|
Voltage |
|
12 or 24 VDC ± 10 % |
|
|
|
|
Reliability (MCBF) |
|
37 x 10 lines |
|
|
|
|
Overall Dimensions |
|
102.9 (W) x 91.9 (D) x 57.5 (H) mm |
|
126.9 (W) x 91.9 (D) x 57.5 (H) mm |
|
|
|
|
Mass |
|
approx. 460 g |
|
approx. 550 g |
|
