Specifications

• Printing method:
• Thermal

• Number of dots:
• 384

• Resolution (dots/mm):
• 8

• Printing width (mm):
• 48

• Paper width (mm):
• 58

• Max. paper thickness (um):
• 80

• Paper loading:
• Easy loading

• Printing speed (mm/s):
• 85

• Paper detection:
• Opto sensor

• Temperature detection:
• Thermistor

• Head-up or Cover-open detection:
• Opto sensor

• Voltage range (Logic | Head):
• 2.7-5.5 V | 4.5-9.5 V

• Dot resistance (Ohm):
• 176 ±3%

• Energy per dot (mJ):
• 0.45

• Stepper motor (Ohm):
• Bipolar (12)

• Weight (g):
• 95

• Life/reliability:
• 50km/ 100M pulses

• Operating temperature (°C):
• -5 to +50

• Operating humidity (%):
• 20 to 85 non cond.

• Dimensions (WxDxH mm):
• 79x78x60

• Cutter:
• Tear bar

• Paper roll diam. max. (mm):
• 49.5
