EPL1950

– 10 – Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. – 11 – Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. This unit is a line thermal printer with a built-in auto cutter that is designed compactly and is driven by 24V dc. Line Thermal Printer Unit/EPL1950 Type : EPL1950  Features  Small size, Light weight  Option(Paper auto cutter, Interface circuit, CPU, KANJI ROM)  Specifications Line Thermal Printer Unit  Applications  EFT-POS terminal  Electronic cash register  Medical, Measurement EPL1952S2C EPL1954S2C (With auto paper cutter) Resolution 8 dots/mm Total number of dots 432 dots/mm Printing speed 600 dot-lines/s [max.] (75 mm/s) Paper width 58 mm Number of colums / line 36 (24 dots×12 dots characters) Life 1×108 pulses, 50 km Operating voltage Head, Motor Auto paper cutter 24 V dc ± 2.4 V dc Logic 5 V dc ± 0.25 V dc Current Head 2.5 A [max.] (at 26.4 V, 144 dots coloring) Motor 0.3 A [max.] Cutting method — PARTIAL cut Cutting time — 0.7 s Cutting life — 0.3 million times (M.C.B.F) Mass (typ.) 75 g 130 g Dimensions (W×D×H) 82 mm×41 mm×15.8 mm 82 mm×41 mm×25 mm
